ALL ORDERS $9.99 FLAT RATE SHIPPING  (excludes HI & AK)

Harris Gas Regulator - 3000 psi - 125 psi - CGA-580 - Argon - Helium - Nitrogen | 3300912

Brand: Harris Products
Manufacturer Part #:

3300912


Welding Supply Part Number: HAR3300912
 /

  • Save 27%
    $412.57 $300.68 / Each
  •  Standard Delivery

Harris Gas Regulator - 3000 psi - 125 psi - CGA-580 - Argon - Helium - Nitrogen

Features

  • Economical, two-stage regulator for welding applications where neoprene diaphragms are acceptable
  • Designed for constant delivery pressure over a wide range of inlet pressures
  • Easy-to-operate brass T screw adjusting handle
  • 2 in Painted steel dual scale easy-to-read gauges
  • One-piece encapsulated seat design with internal filter to protect the PTFE Teflon seat from particulate contamination
  • Conforms to CGA E-4 standard
  • Equipped with a tamper proof, self-reseating internal high pressure safety relief valve

    • Brand Harris Products
    Body Material Brass
    Gas Service Argon, Helium, Nitrogen
    Inlet Connection CGA-580
    Maximum Inlet Pressure 3000 psi
    Maximum Outlet Pressure 200 psi
    Minimum Outlet Pressure 125 psi
    Number of Stages Two
    Outlet Connection 9/16-18 RH
    Product Type Gas Regulator
    Diaphragm Material Neoprene
    MFG 3300912

    Description

    Harris Gas Regulator - 3000 psi - 125 psi - CGA-580 - Argon - Helium - Nitrogen

    Features

  • Economical, two-stage regulator for welding applications where neoprene diaphragms are acceptable
  • Designed for constant delivery pressure over a wide range of inlet pressures
  • Easy-to-operate brass T screw adjusting handle
  • 2 in Painted steel dual scale easy-to-read gauges
  • One-piece encapsulated seat design with internal filter to protect the PTFE Teflon seat from particulate contamination
  • Conforms to CGA E-4 standard
  • Equipped with a tamper proof, self-reseating internal high pressure safety relief valve
